The perfect replacement for Truck lead acid Starting batteries!
• Max Power Capacity; carries almost double the
power of regular batteries
• Lightweight
• CE Certified
• Quick charging
Certificate :
UN 38.3; CELead Time :
30 daysWarranty :
5 yearsMOQ :
10Cycle times :
＞4000BMS Protection :
Charging Overcurrent /Short circuit / High temperature• Smart Internal Battery Management System (BMS) protects against:
• Over and under voltage
• Over and under temperature
• Charge and discharge over current
• Short circuit protection
• 10-year Lifespan
| Lithium Iron Phosphate (LiFePO4) | |
| Nominal Voltage | 25.6V |
| Rated Capacity | 210Ah |
| Absorption Voltage | 28.4 to 29.2 V |
| Float Voltage | 28.0 to 28.4 V |
| Equalize Voltage (if applicable) | 28.4 to 29.2 V (same as absorption) |
| Absorption Time | 60 to 120 minutes |
| Temperature Compensation | No |
| Charge Cut-off Voltage | 29.2 V |
| Discharge Cut-off Voltage | 20 V |
| Recommended Charge Current | 100A |
| Recommended Discharge Current | 100A |
| Maximum Continuous Charge Current | 200A |
| Maximum Continuous Discharge Current | 200A |
| CCA | 2500A |
| Bluetooth connection | No |
| Self Heating | Optional |
| IP Standard | IP54 |
| BMS Protection | Charging Overcurrent Short circuit High temperature |
| Internal Resistance | ≤5mΩ |
| BMS Leakage Current | ≤30μA |
| Battery Leakage Current | ≤3mA |
| Operating Temperature Charge | 32°F (0°C) to 131°F (55°C) |
| Operating Temperature Discharge | -4°F (-20°C) to 131°F (55°C) |
| Storage Temperature 1 week | -4(-20°C) to 149°F (65°C) |
| Storage Temperature 1 month | -4°F (-20°C) to 113°F(40°C) |
| Storage Temperature 1 year | -4°F (-20°C) to 77°F (25°C) |
| Humidity Operating: | 5% to 90 % RH |
| Humidity Storage: | 35% to 85% RH |
| Certifications UN 38.3; CE | |
| Cycle Life | 3000-5000 cycles |
| Product Lifespan | 10-year (Prorated) |
| Connected in series or parallel | |
