3U Rack Mount Lithium Ion Battery
3U Rack Mount Lithium Ion Battery
3U Rack Mount Lithium Ion Battery
3U Rack Mount Lithium Ion Battery
3U Rack Mount Lithium Ion Battery
3U Rack Mount Lithium Ion Battery
3U Rack Mount Lithium Ion Battery
3U Rack Mount Lithium Ion Battery

3U Rack Mount Lithium Ion Battery

·Highest safety, battery is made from LiFePO4 chemistry and comply with highest international safety and transport standard.

·Modular and flexible, support up to 15 batteries connect together to expand the system energy.

·Build-in pre-charge circuit to avoid rush current when connecting with different inverter/chargers.

·Automatic dynamic addressing function when connected multiple batteries together.

·Rapid shut down function for North American market.

·Support a maximum of 96% DOD under off-grid and back-up application

·Built in BMS provide warning and protection functions including over-discharged, over-charged, over- current, short-circuit and high/low temperature.

·LiFePO4 as cathode material and automatic balancing function to meet long cycle life

·Compact size and light weight for easy installation and maintenance.

·CAN/RS485 port for external communication and upgrade the BMS firmware.

  • Certificate :

    UN38.3,CE
  • Lead Time :

    30 days
  • Warranty :

    5 years
  • MOQ :

    10
  • Cycle times :

    6000
  • BMS Protection :

    Charging Overcurrent ,Short circuit, High/Low temperature



Nominal Voltage 51.2 V
Rated Capacity 100Ah
Absorption Voltage 56.8 to 58.4 V
Float Voltage 56.0 to 56.8 V
Equalize Voltage (if applicable) 56.8 to 58.4 V (same as absorption)
Absorption Time 60 to 120 minutes
Temperature Compensation No
Charge Cut-off Voltage 58.4 V
Discharge Cut-off Voltage 40 V
Recommended Charge Current 50A
Recommended Discharge Current 50A
Maximum Continuous Charge Current 100A
Maximum Continuous Discharge Current 100A
Peak Discharge Curren 120A
Bluetooth connection Yes
Self Heating No
IP Standard IP30
Communication CAN/RS485/RS232
Switch Yes
BMS Protection Charging Overcurrent
Short circuit
High/Low temperature
Internal Resistance ≤30mΩ
BMS Leakage Current ≤3mA
Operating Temperature Charge 32°F (0°C) to 131°F (55°C)
Operating Temperature Discharge  -4°F (-20°C) to 131°F (55°C)
Storage Temperature 1 week  -4(-20°C) to 149°F (65°C)
Storage Temperature 1 month  -4°F (-20°C) to 113°F(40°C)
Storage Temperature 1 year  -4°F (-20°C) to 77°F (25°C)
Humidity Operating: 5% to 90 % RH
Humidity Storage: 35% to 85% RH
Certifications UN 38.3; CE
Cycle Life 6000 cycles
Product Lifespan 10-year (Prorated)
 Maximum Parallel
15 units
