Long-Lasting A-Grade Performance
Experience superior energy density and stable performance with ECO-WORTHY's premium A-grade LiFePO4 cells. With over 4,000 cycles and an extensive operating temperature range (charging: 0~55℃, discharging: -20~55℃), this battery lasts 8 times longer than traditional lead-acid alternatives.
Dual Monitoring System
Stay in complete control with two convenient ways to monitor your battery status. The Bluetooth connectivity enables wireless monitoring via smartphone, while the intelligent display screen provides accurate real-time data on battery percentage, voltage, current, and capacity for smarter power management.
Lightweight & Compact Design
Weighing only 37.6kg with dimensions of 520×268×219mm, this ECO-WORTHY battery is incredibly easy to handle and install. The plastic shell construction and compact size make it ideal for golf carts and other mobile applications where weight and space matter.
Advanced BMS Protection
Rely on the robust Battery Management System that safeguards against high/low temperatures, short circuits, overcurrent, and overload. The exceptional thermal and chemical stability of LiFePO4 technology eliminates regular maintenance, saving you time and maintenance costs.
Wide Compatibility & Stackable Design
Perfectly designed for 48V systems including major golf cart brands (YAMAHA, Club Car, EZ GO), lawnmowers, RVs, trolling motors, and marine applications. The stackable design maximizes space efficiency, making it versatile for various power storage needs.
|
SPECIFICATION |
DETAILS |
|
Power (Wh) |
5120 Wh |
|
Rated Voltage |
51.2V |
|
Operation Voltage |
40-58.4V |
|
Standard Charge/Discharge |
50A/50A |
|
Maximum Continuous Charge/Discharge |
200A/200A |
|
Peak Current |
250A/30s |
|
Maximum Peak Current |
700A/1s |
|
Number of Series and Parallel Connections |
4P1S |
|
Charging Voltage |
58.4V |
|
Dimensions (mm/inch) |
520*268*219mm / 20.47*10.55*8.62inch |
|
Rated Capacity |
100Ah |
|
Weight (kg/lbs) |
37.6kg / 82.9Ibs |
|
Operation Temperature Range |
Charge: 0~55*C, Discharge: -20~55°℃ |
|
Terminal Type |
M8 |
|
Case Material |
ABS |
| Lithium ron Phosphate (iFePO4) | |
| Nominal Vvoltage | 51.2v |
| Rated Capacity | 100AH |
| Charge Method | CcC/cv |
| Charge Voltage | 58.4V |
| Bulk/Absorption Voltage | 58.4 |
| BMS Balancing Voltage | Any cel otage 3.45V Max Vltag difrence between cels >30mV In Charging |
| Equalize Votage | Not appicable |
| Float Voltage * | Not appicable |
| Temperature Compensation | No/ Disable |
| Charge Cut-off Voltage | 58.4V |
| Discharge Cut-off Voltge | 40v |
| Recommended Charge Current | 50A |
| Recommended Discharge Current | 50A |
| Maximum Continuous Charge Current | 200A |
| Maximum Continuous Discharge Current | 200A |
| Peak Current | 250A/30s 700A/1s |
| WiFi | No |
| Bluetooth | Yes |
| Communication | No |
| Self Heating | No |
| Protection Rating | IP65 |
| BMS Protection | . Over and Low votage ·Charge andDischarge Over current Short circut · High and Low tem perature |
| Intermal Re sista nce | s30mΩ |
| BMS Leakage Current | s10mA |
| Charge Temperature Range | 32F (0°C)to 1319F (55°) |
| Discharge Temperature Range | -4°F (-20°C) to 131°F (55°C) |
| Storage Temperature 1 week | -4(-20°C) to 149°F (65°C) |
| Storage Temperature 1 month | -4°F (-20°℃C) to 113*F(40°℃) |
| Storage Temperature 1 year | -4°F (-20°C) to 77°F (25°℃C) |
| Humidity Operating: | 5% to 90 % RH |
| Humidity Storage: | 35% to 85% RH |
